Specifications
| Connection Vacuum Inlet Flange | 3/4" BSPP (or G 3/4") Female 1/2" BSPP (or G 1/2") Female |
| Cooling Method | Air Cooling |
| lubricantProductDefault | LEYBONOL LVO 120 |
| Supply Voltage | 3Ph 220-240/380-415V 50Hz |
| Power Total Rated | 550.00 |
| Pumping Speed Air Nitrogen (@50Hz or max @default setting) | 2.639 × 10⁻³ |
| Pressure Ultimate | 150.00 |
SOGEVAC SV 10 B - WIDE 3Ph GB
Variant
Explore the range of variants given below to compare the product
| Short Description | Part Number |
|---|---|
| 960100 | |
| 960105 | |
| 960110 |
Oil Rotary Vane Pumps Single-Stage
The SOGEVAC vacuum pumps are single stage oil sealed rotary vane pumps, one of the main Leybold products! Leybold is proud of its over 175 years of experience and SOGEVAC exist for over 40 years. SOGEVAC benefit of latest developments in pump technology and regular product portfolio renewal. The comprehensive range allows every customer to select the right pump for his particular needs. SOGEVAC stands out for reliability and sustainability and provides years of exceptional performance.
SOGEVAC B
The SOGEVAC B series of rotary vane vacuum pumps is setting new standards and offers following major characteristics such as compact design and small footprint, better ultimate pressure, very low and constant noise level in any working condition, more integrated functions, improved variant concept and specific customer configurations as well as simplified maintenance. Optimized lubrication and temperature profile allows trouble free operation also in harsh conditions while keeping unrivalled uptime. SOGEVAC B stands out with very high energy efficiency, low and nice noise level and extremely low oil carry over.
General Product Information
| Connection Vacuum Inlet Flange |
3/4" BSPP (or G 3/4") Female
1/2" BSPP (or G 1/2") Female |
| Cooling Method | Air Cooling |
| Dimension Height | 0.199 |
| Dimension Length | 0.315 |
| Dimension Width | 0.281 |
| IP Rating | IP55-F |
| Supply Frequency |
50 Hz
60 Hz |
| Power Supply Phase | 3-Ph |
| Supply Voltage | 3Ph 220-240/380-415V 50Hz |
| Weight | 20.00 |
| Dimension Comments | The dimensions length, width and height try to describe the outer shape of this particular product in its typical orientation when standing on the ground. We always recommend checking the detailed dimensions given in 2D drawings in the instruction manual or the 3D shapes given in 3D models. |
| Connection Inlet / Outlet Flange | 3/4" BSPP (or G 3/4") Female | |
Lubricants
| lubricantProductDefault | LEYBONOL LVO 120 |
Performance Data
| Power Total Rated | 550.00 |
| Power Total Rated @50Hz | 550.00 |
| Power Total Rated @60Hz | 750.00 |
| Pressure Ultimate | 150.00 |
| Pressure Water Vapour Max |
1000.00
1000.00 |
| Pumping Speed Air Nitrogen (@50Hz or max @default setting) | 2.639 × 10⁻³ |
| Pumping Speed Air Nitrogen 50Hz | 2.639 × 10⁻³ |
| Pumping Speed Air Nitrogen 60Hz | 3.194 × 10⁻³ |
Environmental Conditions
| Temperature Ambient Operation Max | 40.00 |
| Temperature Ambient Operation Min | 12.00 |
Classification
| Dry or Wet Pump | Wet |
| Product Pressure Range | Rough Vacuum: 1000 mbar - 1 mbar |
| High / Medium / Rough Vacuum Classification | Rough Vacuum Pump |
| Vacuum Pump Technology | Oil Rotary Vane Pump Single-Stage |
Material of Construction
| Material of Construction | Bronze, Steel, cast iron, Aluminium, FPM (FKM), Glass, Polyamid 6.6, Filter material (Polymers, Paper),Epoxy resin and glass fibre,Copper |
- 300270017_002_Instructions.pdf - English - Instructions
- 3611041002_SOGEVAC_Overview_EN_web.pdf - English - Sales Material
- 300270017_003_Instructions.pdf - French - Instructions
- 300270017_001_Instructions.pdf - German - Instructions
- 3611041001_SOGEVAC_Overview_DE_web.pdf - German - Sales Material
- 3611041004_SOGEVAC_Overview_IT_web.pdf - Italian - Sales Material
- 3611041004_SOGEVAC_Overview_IT_web.pdf - Italian - Sales Material
- 3611041021_SOGEVAC_Overview_JA_web.pdf - Japanese - Sales Material
- 3611041014_SOGEVAC_Overview_KO_web.pdf - Korean - Sales Material
- 3611041035_SOGEVAC_Overview_PT-BR_web.pdf - Portuguese (European), Brazilian Portuguese - Sales Material
- 300270017_011_Instructions.pdf - Simplified Chinese - Instructions
- 3611041036_SOGEVAC_Overview_ZH-CN_web.pdf - Simplified Chinese - Sales Material
- 3611041011_SOGEVAC_Overview_ZH-TW_web.pdf - Traditional Chinese - Sales Material
- 3611041011_SOGEVAC_Overview_ZH-TW_web.pdf - Traditional Chinese - Sales Material
| Product Title | Part Number | Price | Add to cart |
|---|---|---|---|
| Exhaust Filter Gauge - 3/4" BSPP (G) Male | 95193 | - | |
| SEPARATOR LS 25 | 95138 | - | |
| EXHAUST FILTER SV10-16 B | 71413280 | EUR 62.80 | |
| EXHAUST FLANGE G3/4 V10/16B | 971433140 | EUR 191.00 | |
| Clamping Ring - (ADC 12) AL DN 10 /16 ISO-KF | 18341 | EUR 6.40 | |
| Centring Ring - Al (CR) Neopren O-Ring DN 16 ISO-KF | 18326 | EUR 5.70 | |
| Filter F16-25 metal - 1/2" | 71127093 | - | |
| Filter Dust - F 16-25 polyester 1/2" BSPP (G) Female Female (10 to 25 m3 /h) | 71127094 | - | |
| FILTER F16-25 PAPER - 1/2" | 95150 | - | |
| THREAD. FLANGE ADAPTER 16KF 1/2" BSPP (G) Male | 71118120V | - | |
| Adapter / Reducer - DN 16 KF -- 25mm hose | 71118300V | - | |
| Filter F16-25 activated charcoal - 1/2" | 71127092 | EUR 511.00 | |
| SCREW IN NIPPLE G1/2" M - 25 KF | EK6510222 | EUR 161.00 | |
| REDUCTION AND O-RING SV25 B G3/4 - G1/2 | 95124 | - | |
| Exhaust Filter Gauge - 1/2" BSPP (G) Male | 95192 | - |
| Product Title | Part Number | Price | Add to cart |
|---|---|---|---|
| LEYBONOL LVO 120, 1 LITER | L12001 | EUR 35.80 | |
| SET OF SEALS SV10 B-16 B | 71422220 | EUR 138.00 | |
| REPAIR KIT SV10 B-16 B | 71422230 | EUR 281.00 | |
| SERVICE KIT SV10 B-SV16 B | 971444430 | EUR 103.00 | |
| EXHAUST FILTER SV10-16 B | 71413280 | EUR 62.80 | |
| EXHAUST FLANGE G3/4 V10/16B | 971433140 | EUR 191.00 |
